Bimota DB7 Oronero Spec
|
| Engine and transmission |
Engine type: Ducati liquid cooled twin cylinder 4 stroke á 90°,
4 Valves per cylinder desmodronic engine management
|
| Displacement: 1099 cc |
| Bore x stroke: 104 x 64.7 mm |
| Compression rate: 12.5:1 |
| Injection : Walbro By Bimota |
| Power: 160 HP at 9750 rpm |
| Torque: 118 Nm at 8000 rpm |
| Gear box: 6 Speed |
| Clutch: Dry Clutch Multi Disc |
| |
| Chassis, suspension, brakes and wheel |
| Carbon fibre grid frame and milled aluminium parts 6082 |
| Front forks: Marzocchi upside-down 43 mm DLC, fully adjustable |
| Suspension rear: Bimota exclusive Extreme Tech adjustable traction and compression unit, pre-loaded spring |
| Front brakes: 2 Brake discs 320 mm, 4-piston Brembo radial calipers MONOBLOCK |
| Rear brakes: Brake disc 220 mm, 2-piston Bimota brake caliper |
| Front wheel: 120/70_17 |
| Rear wheel: 190/55_17 |
| Overall dimensions: 2100l x 720w x 1120h mm |
| Seat height: 800 mm |
| Wheelbase: 1390 mm |
| Dry weight: 159 Kg |
| Fuel tank: 18 L |
| |
| |
| |
| |
| |
