Bimota DB8 Spec
|
| Engine and transmission |
Engine type: Ducati liquid cooled twin cylinder, 4 stroke L shape,
4 Valves per cylinder, desmodromic engine management
|
| Displacement: 1198 cc |
| Bore x stroke: 106 x 67.9 mm |
| Compression rate: 12.7:1 |
| Injection : Walbro By Bimota |
| Power: 170 HP at 9750 rpm |
| Torque: 127 Nm at 8000 rpm |
| Gear box: 6 Speed |
| Clutch: Dry Clutch Multi Disc |
| |
| Chassis, suspension, brakes and wheel |
| Grid frame 39NiCrMo4 with milled aluminium parts 6082 |
| Front forks: Marzocchi Upside-Down 43 mm DLC, fully adjustable |
| Suspension rear: Bimota exclusive Extreme Tech adjustable traction and compression unit, pre-loaded spring |
| Front brakes: 2 Brake discs 320 mm, 4-piston Brembo radial calipers MONOBLOCK |
| Rear brakes: Brake disc 220 mm, 2-piston Bimota brake caliper |
| Front wheel: 120/70_17 |
| Rear wheel: 190/55_17 |
| Overall dimensions: 2040l x 730w x 1105h mm |
| Seat height: 800 mm |
| Wheelbase: 1430 mm |
| Dry weight: 164 Kg |
| Fuel tank: 18 L |
| |
| |
| |
| |
| |
