Bimota DB8 Spec |
|
Engine and transmission | |
Engine type: Ducati liquid cooled twin cylinder, 4 stroke L shape, 4 Valves per cylinder, desmodromic engine management |
|
Displacement: 1198 cc | |
Bore x stroke: 106 x 67.9 mm | |
Compression rate: 12.7:1 | |
Injection : Walbro By Bimota | |
Power: 170 HP at 9750 rpm | |
Torque: 127 Nm at 8000 rpm | |
Gear box: 6 Speed | |
Clutch: Dry Clutch Multi Disc | |
Chassis, suspension, brakes and wheel | |
Grid frame 39NiCrMo4 with milled aluminium parts 6082 | |
Front forks: Marzocchi Upside-Down 43 mm DLC, fully adjustable | |
Suspension rear: Bimota exclusive Extreme Tech adjustable traction and compression unit, pre-loaded spring | |
Front brakes: 2 Brake discs 320 mm, 4-piston Brembo radial calipers MONOBLOCK | |
Rear brakes: Brake disc 220 mm, 2-piston Bimota brake caliper | |
Front wheel: 120/70_17 | |
Rear wheel: 190/55_17 | |
Overall dimensions: 2040l x 730w x 1105h mm | |
Seat height: 800 mm | |
Wheelbase: 1430 mm | |
Dry weight: 164 Kg | |
Fuel tank: 18 L | |
