Bimota DB10 Bimotard Spec
|
| Engine and transmission |
Engine Type: Ducati 1100DS engine. L-twin. V2, four-stroke
|
| Displacement: 1078cc |
| Bore x Stroke 98.0 x 71.5 mm |
| Compression rate: 10.7:1 |
| Injection : Walbro By Bimota |
| Power: 98 HP @ 7500 RPM |
| Torque 105 Nm @ 5500 RPM |
| Gear box: 6 Speed |
| Clutch: Dry Multi Disc |
| Speed: 220km/h |
| Valves per cylinder: 2 |
| Fuel system: Injection. Magneti Marelli-45mm throttle body |
| |
| Chassis, suspension, brakes and wheel |
| Front Suspension: 43mm telescopic fork |
| Rear Suspension: Monoshock, fully adjustable |
| Front Tyre dimensions: 120/70-17 |
| Rear Tyre dimensions: 180/55-17 |
| Front Brakes: Single disc Brembo, 4 piston, 4 pads with radial Brembo calipers |
| Front brakes diameter: 320 mm |
| Rear brakes diameter 220 mm |
| Wheels: Forged Aluminium |
| Dry Weight: 168 kg |
| Power/weight ratio: 0.5833 HP/kg |
| Seat height: 820 mm |
| Overall Height 1330 mm |
| Overall length: 2045 mm |
| Wheelbase: 1465 mm |
| Fuel Capacity: 13.5 Litres |
| Colour: Red/White/Green |
| |
